EMERSON – ASCO 5/3 W3 Pneumatic Solenoid Valve – Pilot/Pilot G 1/4 521 Series 230V ac

Function: 5/3 W3

Mounting Style: Manifold

Solenoid Fitted: Yes

Minimum Operating Temperature: +5°C

Maximum Operating Pressure: 8bar

Maximum Flow Rate: 1050L/min

Thread Standard: G

Connection Port Thread: G 1/4

Solenoid Voltage: 230V ac

Thread Size: 1/4in

Number of Ports: 5/3

Body Material: Anodised Aluminium

Manufacturer Series: 521 Actuation Type: Pilot/Pilot Minimum Operating Pressure: 1.5bar Maximum Operating Temperature: +50°C Solenoid Power Consumption: 2VA

This is 5/3 W3 Pneumatic Solenoid Valve – Pilot/Pilot G 1/4 521 Series 230V ac manufactured by EMERSON – ASCO. The manufacturer part number is 52100089. It performs basic function of 5/3 w3. The product is available in manifold style. It includes a fitted solenoid yes . Whereas, the minimum operating temperature of the product is +5°c. It features 8bar maximum operating pressure. The product provides up to 1050l/min maximum flow rate. The threaded is a g standard. It also features g 1/4 connection port thread. It has 230v ac solenoid voltage . It has a typical thread size of 1/4in. This product features 5/3 number of ports. The product’s body is nicely designed from anodised aluminium materials. The product has a 521 manufacturer series. It also features pilot/pilot actuation. It has a minimum 1.5bar operating pressure . It has a maximum operating temperature of +50°c. Its solenoid power consumption is approximately 2va .
