EMERSON – AVENTICS 5/3 Pneumatic Solenoid Valve – Pilot/Pilot G 1/8 TC08 Series 24V dc

Function: 5/3

Mounting Style: Manifold

Solenoid Fitted: Yes

Minimum Operating Temperature: -10°C

Maximum Operating Pressure: 10bar

Maximum Flow Rate: 700L/min

Thread Standard: G

Connection Port Thread: G 1/8

Solenoid Voltage: 24V dc

Thread Size: 1/8in

Number of Ports: 5/3

Body Material: Fibreglass Reinforced PA

Manufacturer Series: TC08 Actuation Type: Pilot/Pilot Minimum Operating Pressure: 3bar Maximum Operating Temperature: +50°C Solenoid Power Consumption: 2.2W

This is 5/3 Pneumatic Solenoid Valve – Pilot/Pilot G 1/8 TC08 Series 24V dc manufactured by EMERSON – AVENTICS. The manufacturer part number is R422100976. It performs basic function of 5/3. The product is available in manifold style. It includes a fitted solenoid yes . Whereas, the minimum operating temperature of the product is -10°c. It features 10bar maximum operating pressure. The product provides up to 700l/min maximum flow rate. The threaded is a g standard. It also features g 1/8 connection port thread. It has 24v dc solenoid voltage . It has a typical thread size of 1/8in. This product features 5/3 number of ports. The product’s body is nicely designed from fibreglass reinforced pa materials. The product has a tc08 manufacturer series. It also features pilot/pilot actuation. It has a minimum 3bar operating pressure . It has a maximum operating temperature of +50°c. Its solenoid power consumption is approximately 2.2w .
