Mean Well PSD 15 14.4W Isolated DC-DC Converter Chassis Mount, Vin 18 → 36 V dc, Vout 24V dc

Number of Outputs: 1

Output Voltage Adjustment Range: ±2%

Load Regulation: ±0.5%

Isolation Voltage: 1.5kV ac

Standards Met: CE Certified, EN 55022 (CISPR22) Class B, EN 55024, EN 61000-4-2, -3, -4, -6, -8, EN 61000-6-1

Mounting Type: Chassis Mount

Efficiency: 78%

Maximum Temperature: +60°C

Series: PSD 15

Input Voltage Range: 18 → 36 V dc

Isolated: Yes

Width: 49mm

Depth: 25mm Output Voltage: 24V dc Length: 94mm Minimum Temperature: -10°C Input Voltage Nominal: 24 V dc Power Rating: 14.4W Output Current: 600mA

This is PSD 15 14.4W Isolated DC-DC Converter Chassis Mount Vin 18 → 36 V dc Vout 24V dc manufactured by Mean Well. The manufacturer part number is PSD-15B-24. Additionally, the product is supplied with 1 outputs. It has ±2% of output voltage adjustment range. Load Regulation – ±0.5%. It has 1.5kv ac isolation voltage. The product complies with all safety standards, such as ce certified, en 55022 (cispr22) class b, en 55024, en 61000-4-2, -3, -4, -6, -8, en 61000-6-1. The product is available in chassis mount configuration. It is a highly efficient product with an 78% of high efficiency. The product has +60°c maximum temperature. The product psd 15, is a highly preferred choice for users. It has 18 → 36 v dc of input voltage range. Isolated options – yes. Furthermore, the product is 49mm wide. The product comes in 25mm depth. Features a 24v dc output voltage. Its accurate length is 94mm. While its minimum temperature is -10°c. It has 24 v dc of nominal input voltage. Feature 14.4w of power rating. It carries 600ma output current.
