Norgren – V04B286M-B428A – V04 G 1/4 2/2 Solenoid/Spring Inline, Manifold Pneumatic Control Valve, 190L/min

Function: 2/2

Mounting Style: Inline, Manifold

Solenoid Fitted: Yes

Minimum Operating Temperature: -20°C

Maximum Operating Pressure: 10bar

Maximum Flow Rate: 190L/min

Thread Standard: G

Connection Port Thread: G 1/4

Solenoid Voltage: 110→120V ac

Thread Size: 1/4in

Number of Ports: 2/2

Body Material: Brass

Manufacturer Series: V04 Actuation Type: Solenoid/Spring Minimum Operating Pressure: 0bar Maximum Operating Temperature: +50°C

Excel Valves Extensive range of power consumption and flow rate options G 1/ 8, G 1/ 4 and 7mm interface porting Standard exhaust diffuser DIN 43650 Form A electrical connection, connector plug must be ordered separately Protection rating IP65, with connector plug Glass reinforced removable nylon coil with stainless iron armature Polyester interface Stainless steel tube and spring Zinc alloy base (G 1//8), brass base (G 1//4) Nitrile seals Valve comes with solenoid coil Operating Pressure (bar) Temperature Range (°C) 0 to 10 -20 to +50
