Portescap 22V28-213E.201

Shaft Diameter: 2mm

Current Rating: 1.15 A

Dimensions: 22 (Dia.) x 34.4 mm

Output Speed: 7600 rpm

Maximum Output Torque: 8.48 mNm

DC Motor Type: Brushed

Length: 34.4mm

Supply Voltage: 12 V dc

Power Rating: 4.5 W

Core Construction: Ironless

Torque – Rated (oz-in / mNm): 1.201 / 8.48

HTSUS: 8501.10.4060

RoHS Status: RoHS Compliant Termination Style: Solder Tab Power – Rated: 4.2W Operating Temperature: -30°C ~ 85°C Approval Agency: – Motor Type: Brushed Type: DC Motor Function: Standard Voltage – Rated: 12VDC Mounting Hole Spacing: 0.669″ (17.00mm)Length – Shaft and Bearing: 0.402″ (10.20mm) RPM: 10000 RPM Diameter – Shaft: 0.079″ (2.00mm) Package: Tray Encoder Type: – Size / Dimension: Round – 0.866″ Dia (22.00mm) Gear Reduction Ratio: – standardLeadTime: 26 Weeks Moisture Sensitivity Level (MSL): 1 (Unlimited) Features: – Weight: 0.15 lb (68.04 g) Series: 22V28 Torque – Max Momentary (oz-in / mNm): -Base Product Number: 22V28 ECCN: EAR99

This ismanufactured by Portescap. The manufacturer part number is 22V28-213E.201. The diameter of the shaft is 2mm. The product has a current rating of 1.15 a. The given dimensions of the product include 22 (dia.) x 34.4 mm. Its output speed is 7600 rpm . Its maximum output torque is about 8.48 mnm . In addition, in includes a brushed type DC motor . Its accurate length is 34.4mm. Features 12 v dc supply voltage. Feature 4.5 w of power rating. Moreover, it has a/an ironless core construction . It has a rated torque (oz-in / mNm) of 1.201 / 8.48. It is assigned with possible HTSUS value of 8501.10.4060. The product is rohs compliant. Moreover, it has solder tab terminal style. It features a power rating of 4.2w. The product has -30°c ~ 85°c operating temperature range. This high-efficiency motor is a brushed. It comes in dc motor configuration. It performs basic function of standard. It also exhibits voltage rating of 12vdc. It has a 0.669″ (17.00mm) mounting hole space. The typical length of shaft and bearing is 0.402″ (10.20mm). It provides maximum rpm up to 10000 rpm. Shaft with a 0.079″ (2.00mm) diameter. It is shipped in tray package . The product’s diameters include round – 0.866″ dia (22.00mm). It has a long 26 weeks standard lead time. Its typical moisture sensitivity level is 1 (unlimited). The typical product’s weight is 0.15 lb (68.04 g). The product 22v28, is a highly preferred choice for users. Moreover, it corresponds to 22v28, a base product number of the product. The product is designated with the ear99 code number.
