Q3204DC21006800 Crystal Oscillator, 10 MHz, ±50ppm CMOS 25pF, 4-Pin PDIP, 13.7 x 6.6 x 5.3mm

Dimensions: 13.7 x 6.6 x 5.3mm

Mounting Type: Through Hole

Output Level: CMOS

Oscillator Type: XO

Height: 5.3mm

Frequency Stability: ±50ppm

Width: 6.6mm

Length: 13.7mm

Package Type: PDIP

Output Frequency: 10MHz

Minimum Operating Temperature: -20°C

Maximum Operating Temperature: 70°C

This is Crystal Oscillator 10 MHz ±50ppm CMOS 25pF 4-Pin PDIP 13.7 x 6.6 x 5.3mm manufactured by Epson. The manufacturer part number is Q3204DC21006800. The given dimensions of the product include 13.7 x 6.6 x 5.3mm. The product is available in through hole configuration. Its output level is cmos . The product is a xo type of oscillator. In addition, the height is 5.3mm. It also carries ±50ppm of stable frequency value. Furthermore, the product is 6.6mm wide. Its accurate length is 13.7mm. The package is a sort of pdip. This product has an output frequency range of 10mhz. Whereas, the minimum operating temperature of the product is -20°c. It has a maximum operating temperature of 70°c.
