Recom Through Hole 2W Isolated DC-DC Converter, Vin 21.6 → 26.4 V dc, I/O isolation 1000V, Vout ±12V dc

Number of Outputs: 2

Load Regulation: ±10%

Isolation Voltage: 1kV dc

Efficiency: 81 → 85%

Mounting Type: Through Hole

Package: SIP

Maximum Temperature: +85°C

Series: RD

Input Voltage Range: 21.6 → 26.4 V dc

Length: 19.65mm

Isolated: Yes

Width: 7.05mm

Depth: 10.2mm Output Voltage: ±12V dc Minimum Temperature: -40°C Input Voltage Nominal: 24 V dc Power Rating: 2W Output Current: ±84mA

This is Through Hole 2W Isolated DC-DC Converter Vin 21.6 → 26.4 V dc I/O isolation 1000V Vout ±12V dc manufactured by Recom. The manufacturer part number is RD-2412D. Additionally, the product is supplied with 2 outputs. Load Regulation – ±10%. It has 1kv dc isolation voltage. It is a highly efficient product with an 81 → 85% of high efficiency. The product is available in through hole configuration. It is shipped in sip package . The product has +85°c maximum temperature. The product rd, is a highly preferred choice for users. It has 21.6 → 26.4 v dc of input voltage range. Its accurate length is 19.65mm. Isolated options – yes. Furthermore, the product is 7.05mm wide. The product comes in 10.2mm depth. Features a ±12v dc output voltage. While its minimum temperature is -40°c. It has 24 v dc of nominal input voltage. Feature 2w of power rating. It carries ±84ma output current.
