Adhesive Lined: No
Standards Met: BS3G 198 Part 3 11B, CSA C22.2 No. 198.1, IEC 60684-3-212 A&B, MIL SAE-AMS-DTL 23053/5 Class 1, RoHS Compliant, UL 224 VW-1 E48762, VG 95343 Part 5 A&B
Sleeve Diameter: 19.1mm
Operating Temperature Range: -55 → +135 °C
Colour: Clear
Material: Polyolefin
Halogen Free: Yes
Sleeve Type: Heat Shrink
Shrunk Diameter: 9.5mm
Sleeve Length: 300mm
Shrink Ratio: 2:1
Flame Retardant: No
This is Clear Heat Shrink Tubing 2:1 19.1mm Dia. x 30cm manufactured by RS Pro. The manufacturer part number is 443-4968. Its adhesive is lined no . The product complies with all safety standards, such as bs3g 198 part 3 11b, csa c22.2 no. 198.1, iec 60684-3-212 a&b, mil sae-ams-dtl 23053/5 class 1, rohs compliant, ul 224 vw-1 e48762, vg 95343 part 5 a&b. It has a 19.1mm diameter. The product has -55 → +135 °c of operating temperature range. It has a decent clear colour. The product is made from highly stable and reliable polyolefin. It is halogen free yes . This heat shrink sleeve offers extreme flexibility and suit various settings. Moreover, its overall shrunk diameter is 9.5mm . The sleeve has a 300mm length. Its shrink ratio is about 2:1 . It is flame retardant no .
