SY89295UMG, Delay Line 14.8ns, 32-Pin MLF

Maximum Delay Time: 14.8ns

Output Logic Level: LVPECL

Dimensions: 5 x 5 x 0.84mm

Mounting Type: Surface Mount

Minimum Operating Supply Voltage: 2.375 V

Number of Independent Delay Inputs: 1

Logic Function: Delay Line

Input Signal Type: CMOS, LVPECL, LVTTL

Package Type: MLF

Absolute Increment: 0.01ns

Minimum Operating Temperature: -40 °C

Maximum Operating Supply Voltage: 3.6 V

Maximum Operating Temperature: +85 °C Pin Count: 32 Delay to First Tap: 3.2ns

This is Delay Line 14.8ns 32-Pin MLF manufactured by Microchip. The manufacturer part number is SY89295UMG. It has 14.8ns maximum delay time . Moreover, it has a/an lvpecl output logic level . The given dimensions of the product include 5 x 5 x 0.84mm. The product is available in surface mount configuration. While its minimum operating supply voltage is 2.375 v. In addition, it has 1 number of independent delay inputs . The primary function of logic includes delay line. The input signal is a kind of cmos, lvpecl, lvttl signal. The package is a sort of mlf. 0.01ns is the absolute increment of the product . Whereas, the minimum operating temperature of the product is -40 °c. It has 3.6 v maximum operating supply voltage. It has a maximum operating temperature of +85 °c. It contains 32 pins. It has a delay of 3.2ns to first tap .
