Texas Instruments LM5170EVM-BIDIR

Power Management Function: Current Controller

Kit Name: Bidirectional Converter Evaluation Module

Featured Device: LM5170

Kit Classification: Evaluation Module

For Use With: Battery System Applications

Main Purpose: DC/DC, Step Up or Down

HTSUS: 8504.40.9580

RoHS Status: ROHS3 Compliant

Voltage – Input: 3V ~ 48V, 6V ~ 75V

Frequency – Switching: 100kHz

REACH Status: REACH Unaffected

Current – Output: 60A

Board Type: Fully Populated Package: Bulk Moisture Sensitivity Level (MSL): 1 (Unlimited) Regulator Topology: Boost, Buck Utilized IC / Part: LM5170-Q1 Series: – Voltage – Output: 14.5V, 50.5V Supplied Contents: Board(s) ECCN: EAR99 Base Product Number: LM5170 Outputs and Type: 2, Non-Isolated
